Scaffolding For Civil Engineers

NJW Scaffolding

This is the most common type of scaffolding, widely used in the construction of brickwork. Also known as putlog scaffolding, it is primarily used for brick masonry construction. The scaffolding consists of various parts such as scaffold, standard or upright, ledger, putlog or boarer, transom, brace, bracing, guard rail, toe-board, and base plate.

Double scaffolding, sometimes known as independent scaffolding, is stronger than single scaffolding and is used in the construction of stonework. There are two rows of standards used in the construction of this scaffolding. One row is placed just next to the wall and the other row is placed 1.2 to 1.5 metres from the wall.

Suspended scaffolding is a lightweight scaffolding used for repair works such as painting, pointing, whitewashing, distempering, etc., of the exterior surface of the building. The working platform is suspended from the roof by means of wire ropes, chains, etc. The platform can be raised or lowered at any desired level.

Steel scaffolding is similar to timber scaffolding except that wooden members are replaced by steel tubes and rope lashings are replaced by couplets or fittings. Such a scaffolding type can be easily erected and dismantled. It is strong and more durable, but the initial cost is high.

At NJW Scaffolding, we understand that safety is paramount. Scaffolding should be properly maintained and its construction and dismantling should be under the supervision of a competent authority. Every part of scaffolding including their supports should be of good condition, suitable and sound material, and having adequate strength for the purpose for which it is used. The erection, alterations, and removal should be done only under the supervision of men who are thoroughly experienced in this work.
